產(chǎn)品編號(hào)： 2120D1AG1NAAA0000

型號(hào)： 2120 Level Switch

品牌： 羅斯蒙特

Model 2120 Vibrating Fork Liquid Level Switch / –40…302 °F (–40...150 °C)

Materials of construction: process connection/fork D 316/316L Stainless Steel (1.4401/1.4404) dual certified

Process connection size / type 1A 1-in. BSPT (R) Thread

Electronic type G PNP/PLC (3-wire) 20 to 60 Vdc

Surface finish 1 Standard surface finish

Product certifications NA(1) No Hazardous Locations Certifications

Housing A Glass Filled Nylon, M20 conduits/cable threads

Fork length A Standard length 1.7 in. (44 mm)

Specific extended fork length 0000 Factory default length (only if Fork Length A or H is selected)
